Programmable Electronic DC Loads | 400 W - 600 W

EL 9000 T

The EA EL 9000 T Series is a versatile and compact line of programmable DC electronic loads designed for rigorous testing and simulation requirements. Engineered for efficiency and precision, this series offers a wide range of power classes (400 W, 500 W, and 600 W) with advanced features such as integrated function generation, multi-language control panels, and a variety of operation modes. Equipped with extensive safety features and flexible connectivity options, the EL 9000 T Series is a reliable choice for engineers in laboratories, research facilities, and industrial environments.

Key Features

  • Compact Tower Design: Space-saving form factor with power ratings up to 600 W.
  • Integrated Function Generator: Create dynamic waveforms for advanced testing.
  • Multi-Language TFT Touch Panel: Simplifies operation with an intuitive interface.
  • Extensive Safety Features: Includes OVP, OCP, and OTP for secure operation.
  • Flexible Connectivity: Built-in USB with optional Ethernet and analog interfaces.

Why Partner with W5 Engineering?

Expertise

At W5 Engineering, we specialize in power electronics, providing unmatched knowledge of EA Powered products. Our team of technical sales engineers ensures you find the perfect solution for even the most complex requirements.

Custom Solutions

We deliver customized configurations and integrations tailored to your unique applications. Whether for R&D, production, or testing, W5 Engineering ensures your power systems meet exact specifications.

Rapid Shipping

With on-hand inventory and advanced logistics, we minimize lead times to keep your projects on track. Enjoy seamless delivery and peace of mind with our reliable shipping network.

Customer Support

Our dedicated support and technical teams are with you every step of the way, offering expert assistance from installation to troubleshooting. We’re committed to your success with responsive service and training.

Available Models

Product Information

Elevate Your Testing Capabilities with the EA EL 9000 T



The EA EL 9000 T Series combines compact design with powerful functionality, making it ideal for diverse testing environments. Available in power ratings of 400 W, 500 W, and 600 W, this series accommodates input voltages up to 750 V and currents up to 45 A. Its space-saving tower form factor is designed to optimize testing setups without compromising on performance. Engineers will appreciate its intuitive multi-language TFT touch panel, which simplifies operation and enhances usability.

The integrated function generator is a standout feature of the EL 9000 T Series, enabling the creation of dynamic waveforms such as sine, triangle, and square. This capability, combined with modes like constant voltage (CV), constant current (CC), constant power (CP), and constant resistance (CR), ensures comprehensive testing for a wide range of applications. Advanced simulation options like battery discharge and MPP tracking make the EL 9000 T ideal for testing energy storage devices and photovoltaic systems.

Safety and connectivity are prioritized in the EL 9000 T Series. Built-in USB communication is standard, with optional Ethernet and analog interfaces available for seamless integration into automated systems. The series includes robust protection features, including OVP, OCP, and OTP, safeguarding both the equipment and the operator. With its precision, versatility, and reliability, the EL 9000 T Series is a go-to solution for engineers seeking advanced DC load testing capabilities.

Specifications

AC Supply
Voltage: 90…264 V
Frequency: 45…66 Hz
Power consumption: max. 40 W

DC Input Voltage
Accuracy: <0.1% of rated value

DC Current
Accuracy: <0.2% of rated value
Load regulation ±100% ΔIUC: <0.1% of rated value

DC Power
Accuracy: <.05% of rated value

DC-Resistance
Accuracy: ≤1% of max. resistance + 0.3% of rated current

Display / Control Panel
Graphics display with TFT touch panel

Digital Interfaces

  • Equipped as standard:
    • 1x USB type B (for communication) / 1x USB type A (for storage device)
  • Optionally available:
    • 1x Ethernet (not separate, always in combination with USB and analog interface)

    Analog interface

    15 pole D-Sub, galvanically isolated

    Signal range: 0…5 V or 0…10 V (switchable)

    Inputs: U, I, P, R, remote control on-off, DC input on-off, resistance mode on-off

    Outputs: U, I, overvoltage, alarms, reference voltage

    Accuracy U / I / P / R:

        • 0…10 V: ≤0.2%
        • 0…5 V: ≤0.4%

    Cooling
    Temperature controlled fan(s)

    Operation temperature: 0…50 °C
    Storage temperature: -20…70 °C

    Mechanics

    • Dimensions (W x H x D): 92 x 239 x 352 mm (3.6″ x 9.4″ x 13.8″)
    • Weight: 4 kg (8.8 lb)

    Interfaces and Software

    Built-In Interfaces

    Software

      • USB

    Optional Interfaces

      • Analog
      • Ethernet
      • EA Power Control
